I-pulse Label feeder for I-pulse M10/M20/M1/M2/M4 Series SMT machine
Buy a machine to pick and place labels automatically? ----The cost is too high, and the factory floor space is limited.
Is it possible Automatically place labels using existing machine?
Yes! You can do this now.
Label feeder used for I-pulse M10/M20/M1/M2/M4 Series pick and place equipment
Specification:
Parameter
Minimum
Maximum
Label Size
2 x 2mm ( Length x Width)
2mm to customized one (Width)
Label Thickness
0.05mm
1mm
Backing Paper Width
5mm (Width)
5mm to customized one (Width)
Backing Paper Thickness
0.05mm
1mm
Feed Rate
0 mm / sec
95 mm / sec
GOLDLAND Label feeder Features:
l Simple to use.
l Automatically places labels using existing pick-and-place equipment, Labels are simply treated like any other component.
l Not only pastes labels(2D Code ,Barcode, serial number for traceability of the PCB) but also gaskets, double-faced tape, shields, touch pads can be pasted to designated XY position on the board.
l Faster and more accurate than hand placement.
l Reduce manufacturing cost, Eliminate man-hours of manual pasting.
l Correspond to major placement machine models.
l Fits on to the placement machine like any original feeders.
l Saves time and money.
We also supply customized nozzles used to pick and place the labels for ASSEMBLEON , YAMAHA , JUKI , SAMSUNG , PANASONIC , FUJI , PHILIPS , UNIVERSAL , SANYO , I-PULSE , HITACHI, MIRAE , MYDATA and so on.
